BALL VALVE
SORT
Type: Floating, Trunnion, 3-way, V-port, Jacket, Full welded
Application: High pressure, Vacuum, High temperature, Cryogenic, Slurry.
CLASS
150# ~ 2500#
SIZE
1/2” ~ 48”
STANDARD
Design：API 6D, BS5351, ISO17292
Face to Face: API 6D, ANSI B16.1
Flange End: ANSI, JIS, DIN
Mounting Pad: ISO5211
Inspection and Test: API 598, API 6D
Fire Safe: API 607
MATERIAL
Body: WCB/A105, LCB/LF2, CF8/304, CF8M/316, CF3/304L, CF3M/316L, 4A/F51
Trim: WCB/A105 (+Hcr/ENP), CF8/304, CF8M/316, CF3/304L, CF3M/316L,
Seat: PTFE, RPTFE, Carbon, Graphite, Nylon, Peek, Viton, metal seat (e.g. 304 +
Stellited, etc.)
Operation
Manual, Gear Box, Actuator (Electric & Pneumatic)
